Siphon universel pour lavabo Otto Haas avec fermeture à bille

Otto Haas Universal Ball-Pop-Up Basin Siphon

CHF 20 - CHF 22.15

Tax included

Select an option to add this to your cart.

Configuration : DN 32 outlet with ball valve : DN 40 outlet with ball valve : DN 50 outlet with ball valve

Universal trap equipped with an additional ball valve that prevents the backflow of drain gases in areas at risk of drying out or with unfavorable hydraulics. Compatible with DN 40 (1 1/2") and DN 32 (1 1/4") inlets. Supplied with connection sleeve and escutcheon.

Features

Universal trap with integrated ball valve
Protection against drain gas backflow
Compatible inlets: DN 40 (1 1/2") and DN 32 (1 1/4")
Ideal for areas at risk of drying out or with poor hydraulics
Supplied with appliance connection sleeve and escutcheon
Available with DN 32, DN 40, or DN 50 outlet pipe

Technical Data

Brand	Otto Haas
Drainage connection	Push-fit sleeve
Outer diameter of drain pipe [mm]	DN 32 outlet with ball valve: 32 · DN 40 outlet with ball valve: 40 · DN 50 outlet with ball valve: 50
Shape	P-trap
Dimensions	DN 32 outlet with ball valve: DN 32 x 230 mm · DN 40 outlet with ball valve: DN 40 x 230 mm · DN 50 outlet with ball valve: DN 50 x 230 mm
Odour trap type	mechanical
Material	plastic
Trap drain plug connection	Union nut
Colour	white
Mounting	exposed
Trap tube shape	straight
