IMI Heimeier EMOtec 24 V AC/DC Electrothermal Actuator, normally closed

CHF 19.90
/
Tax included

Select an option to add this to your cart.

Description

  • For underfloor heating manifold
  • With position indicator at the top
  • Normally Closed (NC)
  • Protection class IP 43
  • Power consumption: 3 W (continuous operation)
  • Inrush current: 90 W (at 230 V), 9 W (at 24 V)
  • Closing/opening time: approx. 3 min.
  • Ambient temperature: 0°C...50°C
  • Max. fluid temperature: 100°C
  • Connection: M30 × 1.5
  • Connecting cable: 1 m, 2 × 0.50 mm²
  • Dimensions (W × H): 44.5 × 58 mm

Technical data

Voltage 24 V AC/DC
Manufacturer reference 1827-00,500
Power consumption [W] 3
Color white
Operation normally closed (NC)
Height [mm] 58
Control signal Two-point
Diameter [mm] 44.5
Ambient temperature [°C] 0 — 50
Connection cable length [m] 1
Protection type (IP) IP43
Valve connection M30 × 1.5
Operating time [s] 180
Stroke length [mm] 3.5
Mains voltage 24 V AC/DC
