Uponor S-Press PLUS Reduced Tee

CHF 9.30 - CHF 19.05
/
Tax included

Select an option to add this to your cart.

Uponor S-Press crimp fitting with diameter reduction for sanitary and heating installations. Suitable for potable water up to 70°C/10 bar and heating water up to 80°C/10 bar. Reliable and fast system for multilayer pipe connections.

Features

  • S-Press crimping system for sanitary and heating
  • Potable water: max. temperature 70°C, max. pressure 10 bar
  • Heating water: max. temperature 80°C, max. pressure 10 bar
  • Reduced fitting for transition between two diameters
  • Fast and leak-proof installation
  • Compatible with Uponor multilayer pipes

Technical data

Number of connections 2
Brand Uponor
Surface protection tinned
Connection 1 Press sleeve
Shape straight
DVGW Seal Yes
Suitable for potable water according to UBA positive list Yes
Connection 2 Press sleeve
Dimensions Ø20 mm - Ø16 mm: 20 x 2.25 – 16 x 2.0 mm · Ø25 mm - Ø16 mm: 25 x 2.5 - 16 x 2.0 mm · Ø25 mm - Ø20 mm: 25 x 2.5 - 20 x 2.25 mm · Ø32 mm - Ø20 mm: 32 x 3.0 - 20 x 2.25 mm · Ø32 mm - Ø25 mm: 32 x 3.0 - 25 x 3.0 mm
Length [mm] Ø20 mm - Ø16 mm: 53 · Ø25 mm - Ø16 mm: 60 · Ø25 mm - Ø20 mm: 61 · Ø32 mm - Ø20 mm: 61 · Ø32 mm - Ø25 mm: 68
Execution 1 piece
Max. fluid temperature (continuous operation) [°C] 80
With flat gasket No
Conical No
Max. working pressure [bar] 10
Available variants
  • SKU 90 177 15 : Ø20 mm - Ø16 mm
  • SKU 90 177 16 : Ø25 mm - Ø16 mm
  • SKU 90 177 17 : Ø25 mm - Ø20 mm
  • SKU 90 177 18 : Ø32 mm - Ø20 mm
  • SKU 90 177 19 : Ø32 mm - Ø25 mm
Data sheets
Raccord S-Press PLUS Uponor réduit
Uponor S-Press PLUS Reduced Tee
CHF 9.30 - CHF 19.05
Raccord S-Press PLUS Uponor réduit
Ø20 mm - Ø16 mm 90 177 15
CHF 9.30 /each
Raccord S-Press PLUS Uponor réduit
Ø25 mm - Ø16 mm 90 177 16
CHF 14.25 /each
Raccord S-Press PLUS Uponor réduit
Ø25 mm - Ø20 mm 90 177 17
CHF 14.45 /each
Raccord S-Press PLUS Uponor réduit
Ø32 mm - Ø20 mm 90 177 18
CHF 18.05 /each
Raccord S-Press PLUS Uponor réduit
Ø32 mm - Ø25 mm 90 177 19
CHF 19.05 /each
