KFR combined non-return valve in brass, female fitting, without drain

CHF 15.60 - CHF 95.50
/
Tax included

Select an option to add this to your cart.

Features

  • Compliant with OFESP positive list for drinking water
  • Service temperature: max. +90°C
  • Max. pressure: 10 bar
  • Gasket: EPDM
  • Material: pressed brass
  • With grease chamber stem
  • Without dead space
  • With rising stem
  • With check valve

Technical data

  • Direct passage: yes
  • Surface protection: untreated
  • Connection 1: female thread
  • Connection 2: female thread
  • Spring closing (NC): no
  • Body material: brass
  • Size: DN 15 (1/2")
  • Gasket: rubber
  • Max. fluid temperature (continuous operation) [°C]: 90
  • Operation: handwheel
  • Suitable for liquids: yes
  • Max. operating pressure [bar]: 10
  • Nominal diameter: 1/2 inch (15)
  • DVGW certified: yes
  • Spring opening (NO): no
Available variants
  • SKU 93 090 00 : 1/2"
  • SKU 93 090 01 : 3/4"
  • SKU 93 090 02 : 1"
  • SKU 93 090 03 : 1 1/4"
  • SKU 93 090 04 : 1 1/2"
  • SKU 93 090 05 : 2"
Data sheets
Clapet anti-retour combiné KFR en laiton, raccord femelle, sans vidange
KFR combined non-return valve in brass, female fitting, without drain
CHF 15.60 - CHF 95.50
Clapet anti-retour combiné KFR en laiton, raccord femelle, sans vidange
1/2 in. 93 090 00
CHF 15.60 /each
Clapet anti-retour combiné KFR en laiton, raccord femelle, sans vidange
3/4 in. 93 090 01
CHF 20.45 /each
Clapet anti-retour combiné KFR en laiton, raccord femelle, sans vidange
1" 93 090 02
CHF 28.05 /each
Clapet anti-retour combiné KFR en laiton, raccord femelle, sans vidange
1 1/4 in 93 090 03
CHF 49.15 /each
Clapet anti-retour combiné KFR en laiton, raccord femelle, sans vidange
1 1/2 in. 93 090 04
CHF 57.15 /each
Clapet anti-retour combiné KFR en laiton, raccord femelle, sans vidange
2" 93 090 05
CHF 95.50 /each
