- Display: current flow, delivery head and power consumption
- Dynamic Adapt plus
- Control with mobile devices via Bluetooth with the Wilo-Smart Connect BT module (optional)
- Thermal insulation and connector included
- Delivery without screw connection
Technical data:
- Supply voltage: 230 V/50-60 Hz
- Max. operating pressure: 10 bar
- Body material: grey cast iron (KTL coated)
- Installation length: 180 mm
Available variants
Technical details per variant
25/0.5-4 — Ref. 90 071 87
- Energy efficiency index (EEI): 0.16
- Power [W]: 3-20
- Installation length [mm]: 180
- Protection class (IP): IPX4D
- Pressure class: PN 10
- Nominal diameter: DN 25 (1")
- Body material: Grey cast iron
- Maximum fluid temperature (continuous operation) [°C]: 110
- Type: 25/0.5-4
- External thread: DN 40 (1 1/2")
- Connection: External thread
25/0.5-6 — Ref. 90 071 88
- Energy efficiency index (EEI): 0.18
- Power [W]: 3-40
- Installation length [mm]: 180
- Protection class (IP): IPX4D
- Pressure class: PN 10
- Nominal dimension: DN 25 (1")
- Body material: Grey cast iron
- Max. fluid temperature (continuous operation) [°C]: 110
- Type: 25/0.5-6
- External thread: DN 40 (1 1/2")
- Connection: External thread
30/0.5-4 · DN 32(11/4") — Ref. 90 071 89
- Energy efficiency index (EEI): 0.16
- Power [W]: 3-20
- Installation length [mm]: 180
- Protection class (IP): IPX4D
- Pressure class: PN 10
- Nominal diameter: DN 32 (1 1/4")
- Body material: Grey cast iron
- Maximum fluid temperature (continuous operation) [°C]: 110
- Type: 30/0.5-4
- External thread: DN 50 (2")
- Connection: External thread
30/0.5-6 · DN 32(11/4") — Ref. 90 071 90
- Energy efficiency index (EEI): 0.18
- Power [W]: 3-40
- Installation length [mm]: 180
- Protection class (IP): IPX4D
- Pressure class: PN 10
- Nominal diameter: DN 32 (1 1/4")
- Body material: Grey cast iron
- Max. fluid temperature (continuous operation) [°C]: 110
- Type: 30/0.5-6
- External thread: DN 50 (2")
- Connection: External thread
Data sheets
