Features
For use in hot water circulation, heating, air conditioning, cooling, and industrial systems
- Bluetooth interface for wireless data exchange
- Display shows current flow rate in m³/h, power [W], and cumulative energy consumption [kWh]
- Automatic de-aeration function
- Automatic deblocking function
- Thermal disinfection detection
- Dynamic Adapt plus
- Proportional pressure control
- Constant pressure control
- Multi-Flow Adaption
- Reset function
- Key lock
- Q-Limit max. for limiting the maximum volumetric flow rate
- Q-Limit min. for limiting the minimum volumetric flow rate
- No-Flow Stop
- Automatic night setback
- Critical point control (Δp-c control with external actual value sensor)
- Variable slope of the Δp-v characteristic curve
- Thermal insulation shell included
Technical Data
- Supply voltage: 230V/50-60Hz
- Fluid temperature: +2°C - 110°C
- Ambient temperature: 0°C - 60°C
- Protection class: IPX4D
- Casing material: Stainless steel
Compatible with the Wilo-Smart Balance app
The Wilo-Smart Balance app allows for easy hydraulic balancing. The complete report can be exported as a PDF document for submission to the Federal Office for Economic Affairs and Export Control (BAFA) for settlement.
- Installation length: 180 mm
- Max. operating pressure: 10 bar
- Energy Efficiency Index (EEI): 0.18
- Electrical connection: Connection plug
- Installation length [mm]: 180
- Protection class (IP): IPX4D
- Pressure class: PN 10
- Nominal size: DN 25 (1")
- Casing material: Stainless steel
- Max. fluid temperature (continuous operation) [°C]: 80
- Frequency: 50/60 Hz
- EEI ≤: 0.18
- Connection voltage: 1 x 230 V
- Type: 25/0.5-6
- External thread: DN 40 (1 1/2")
- Nominal diameter: DN 25
- Pump casing connection size: 1 1/2 inch
- Connection: External thread
- Nominal size: DN 25
Available variants
- 25/0.5-6 · DN25 (1") · BL 180 mm
