BWG Bavaria fine filter

CHF 134.10 - CHF 412
/
Tax included

Select an option to add this to your cart.

Characteristics

  • For use with potable water
  • Max. inlet pressure: 16 bar
  • Max. operating temperature: +30°C
  • Mounting position: horizontal
  • Filtration fineness: 90 µm
  • Body: Brass

Technical data

  • kvs value [m³/h]: 4.0
  • Backwashable filter: no
  • Connections: External thread
  • Installation length with connections [mm]: 206
  • With drainage option (connection): no
  • Installation length without connections [mm]: 120
  • Overall length without connection [mm]: 120
  • Installation length [mm]: 120
  • DVGW certification: 315
  • Body material: Brass
  • DVGW label: no
  • Size: DN 20 (3/4")
  • Mounting position: horizontal/vertical
  • Overall height [mm]: 300
  • Type: Bavaria
  • Max. operating pressure [bar]: 16
  • Overall length with connection [mm]: 206
  • Nominal diameter: 3/4 inch (20)
Available variants
  • SKU 93 006 01: DN 20 (3/4")
  • SKU 93 006 02: 1"
  • SKU 93 006 03: DN 32 (1 1/4")
  • SKU 93 006 05: DN 40 (1 1/2")
  • SKU 93 006 06: DN 50 (2")
Technical data sheets
BWG Filtre fin Bavaria
BWG Bavaria fine filter
CHF 134.10 - CHF 412
BWG Filtre fin Bavaria
DN 20 (3/4") 93 006 01
CHF 134.10 /each
BWG Filtre fin Bavaria
1" 93 006 02
CHF 134.10 /each
BWG Filtre fin Bavaria
DN 32 (1 1/4") 93 006 03
CHF 150.50 /each
BWG Filtre fin Bavaria
DN 40 (1 1/2") 93 006 05
CHF 391 /each
BWG Filtre fin Bavaria
DN 50 (2") 93 006 06
CHF 412 /each
